Mitsubishi FX1S-20MR-001

Overview

The Mitsubishi FX1S-20MR-001 is a cornerstone of compact automation, representing a robust PLC main unit from the highly regarded FX1S series. Engineered for efficiency and reliability, this controller provides 20 I/O points, strategically configured with 12 digital inputs and 8 relay outputs, all powered by a stable 24V DC supply. Its remarkably small footprint belies its powerful capabilities, making it the ideal solution for a wide array of basic automation tasks, precise logic sequencing, and seamless integration into OEM machinery. Designed with the demands of modern industrial environments in mind, the FX1S-20MR-001 serves as a dependable workhorse, ensuring consistent performance and simplified control for applications where space is at a premium but reliability is paramount.

Key Features

• Integrated 20 I/O points (12 reliable inputs, 8 robust relay outputs)
• Compact, all-in-one design with embedded relay outputs for space efficiency
• Supports high-speed counters and timers for demanding applications
• Integrated safety diagnostics and error detection ensures operational integrity
• Compatible with powerful GX Developer programming software for ease of use
• UL-certified for industrial use, guaranteeing safety and compliance
• Dust-tight construction provides enhanced durability in challenging environments

Technical Specifications

• Model: FX1S-20MR-001
• Series: FX1S (MELSEC-F)
• Total I/O: 20 points
• Inputs: 12 digital (sink/source)
• Outputs: 8 relay (2 A maximum per point)
• Input Voltage: 24 V DC ±10%
• Power Supply: 24 V DC
• Program Memory: 2,000 steps
• Power Consumption: Approximately 10 W
• Mounting: DIN rail or direct panel mount
• Dimensions: 120 mm (W) × 90 mm (H) × 86 mm (D)
• Protection Class: IP10 (open type)
• Operating Temperature: 0 °C to +55 °C
• Certifications: CE, UL (E175732), cUL

Applications

• Small-scale machine and precision actuator control systems
• Efficient conveyor and sensor integration for material handling
• Basic OEM equipment logic operations and sequential control
• HVAC and intelligent lighting control tasks in commercial settings
• Entry-level automation control panels for various industries
• Simple process control and monitoring in compact setups

Why Choose This Model?

• Compact and Cost-Effective: Delivers a potent PLC solution with relay outputs in a remarkably small and budget-friendly package.
• Easy Integration: Designed for straightforward setup and installation, making it ideal for tight spaces and quick deployment.
• Mitsubishi Reliability: Benefits from Mitsubishi Electric's renowned quality and engineering excellence, backed by comprehensive UL certification.
• Optimized for Small I/O: Perfectly suited for applications with limited I/O requirements, streamlining control and reducing complexity.
• Proven Performance: Boasts a strong track record of success across diverse industrial applications, ensuring dependable operation.
• Global Availability: Readily available and ships worldwide, simplifying procurement and logistics for international projects.

Order Now

Elevate your automation capabilities with the Mitsubishi FX1S-20MR-001 PLC. This compact, feature-rich main unit offers unparalleled reliability and efficiency for a wide range of industrial applications. Secure your competitive edge by adding this indispensable controller to your operations today. Explore our full range of Mitsubishi automation solutions for comprehensive control system options. Available for immediate shipping worldwide, ensuring your projects stay on schedule and within budget.
