GE IC694MDL742

GE IC694MDL742

$1,004.00
$1,004.00

Overview

The GE Fanuc IC694MDL742 is a robust 32-point 24VDC discrete output module meticulously engineered for the demanding PACSystems RX3i platform. This high-density output solution provides reliable control for a wide array of DC-powered devices, from essential solenoids and relays to critical indicators. Its design incorporates sourcing outputs with positive logic, ensuring seamless integration into various industrial control systems. A standout feature is its innovative group isolation, segmenting the outputs into four distinct groups of 8 points. This electrical separation significantly enhances system flexibility, minimizes cross-talk, and bolsters overall reliability, making it an ideal choice for operations requiring stringent safety and precise control.

As a core component within the RX3i series, the IC694MDL742 exemplifies GE Fanuc (Emerson)'s commitment to industrial automation excellence. It provides a compact yet powerful solution for managing numerous output signals, optimizing panel space while delivering uncompromised performance. Whether upgrading an existing system or designing a new one, this module offers the precision and durability expected from leading industrial hardware.

Key Features

  • 32-point 24VDC sourcing outputs with positive logic for comprehensive device control.
  • Four independently isolated groups of 8 outputs for enhanced system flexibility and safety.
  • Integrated overload and short-circuit protection to safeguard connected equipment.
  • Hot-swappable capability for seamless module replacement without system downtime (in supported RX3i systems).
  • Individual green LED status indicators for each of the 32 outputs, simplifying diagnostics and troubleshooting.
  • Robust design engineered for continuous operation in harsh industrial environments.
  • Optimized for integration within the GE Fanuc PACSystems RX3i programmable automation controller platform.

Technical Specifications

  • Model Number: IC694MDL742
  • Series: GE Fanuc PACSystems RX3i
  • Output Type: 24VDC Sourcing (Positive Logic)
  • Channels: 32 (Arranged in 4 groups of 8 outputs)
  • Nominal Voltage: 24VDC
  • Operating Voltage Range: 19.2 – 28.8 VDC
  • Max Output Current: 0.5A per point; 3A per group
  • ON-State Voltage Drop: Less than 0.3 VDC
  • OFF-State Leakage Current: Less than 0.1 mA
  • Minimum Load: 1 mA
  • Power Requirements: 5V @ 160 mA
  • Isolation Voltage: 250V between groups and system logic
  • Operating Temperature: 0°C to 60°C (32°F to 140°F)
  • Certifications: UL Listed, CE Marked
  • Protection: Overload and Short-Circuit Protection on all outputs

Applications

  • Industrial control systems requiring high-density 24VDC output control.
  • Automated machinery for manufacturing, assembly, and packaging.
  • Process automation in industries such as chemical, food and beverage, and water treatment.
  • Control panels and electrical enclosures managing numerous DC-actuated devices.
  • OEM solutions where space-saving and reliable output control are paramount.
  • Building management systems for lighting, HVAC, and security control.

Why Choose This Model?

  • Unmatched Reliability: Built by GE Fanuc (Emerson), a leader in industrial automation, ensuring long-term performance and durability.
  • Enhanced Safety & Flexibility: Group isolation minimizes electrical interference and allows for differentiated load management across output groups.
  • High-Density Control: 32 outputs in a single module reduce the need for multiple smaller modules, saving space and simplifying wiring.
  • Simplified Diagnostics: Individual LED indicators for each output point provide immediate visual feedback on status and aid in rapid troubleshooting.
  • Seamless Integration: Designed specifically for the PACSystems RX3i platform, guaranteeing full compatibility and optimal system performance.
  • Global Availability & Support: Ready to ship worldwide with the backing of a trusted industrial automation brand.

Order Now

Elevate your industrial control capabilities with the GE Fanuc IC694MDL742 RX3i Discrete Output Module. Its combination of high-density outputs, group isolation, and robust design makes it an indispensable component for reliable and efficient automation systems. Don't compromise on performance or safety – secure this essential module for your operations today. Available for worldwide shipping, the IC694MDL742 is ready to power your next project with precision and confidence.
