Beckhoff EL4024

Overview

The Beckhoff EL4024 is a high-performance 4-channel analog output terminal, an integral component of the renowned EtherCAT I/O system. Engineered for precision and reliability, this terminal generates voltage signals within the ±10 V range with an exceptional 12-bit resolution. This capability makes it an ideal solution for accurately controlling a diverse array of actuators, drives, and external devices in sophisticated automation environments. Its compact design and DIN-rail mounting facilitate seamless integration into distributed EtherCAT networks, providing unparalleled flexibility for a wide spectrum of industrial and building automation applications. The EL4024 embodies Beckhoff's commitment to advanced control technology.

Key Features

• Four independent analog output channels for versatile control
• Precise output range of ±10 V, catering to various industrial standards
• High 12-bit resolution for accurate and granular signal generation
• Robust electrical isolation between I/O and the bus system ensures signal integrity and safety
• Compact 12 mm EtherCAT terminal housing optimizes cabinet space
• Integrated diagnostic LEDs provide clear status indication for output and system monitoring
• Full compatibility and seamless integration with Beckhoff TwinCAT software for easy configuration and programming

Technical Specifications

• Model: EL4024
• Manufacturer: Beckhoff
• Channels: 4 analog outputs
• Output Voltage Range: ±10 V
• Resolution: 12-bit
• Electrical Isolation: 500 V (I/O to bus system)
• Housing Width: 12 mm
• Mounting: DIN rail (EtherCAT Terminal system)
• Operating Temperature: –25 °C to +60 °C
• Communication Protocol: EtherCAT
• Current Consumption (typ.): 110 mA (from E-bus)
• Configuration: Via TwinCAT or other EtherCAT master

Applications

• Precise control of actuators and variable frequency drives using analog signals
• Advanced machine and process automation systems requiring accurate analog outputs
• Signal generation for rigorous testing, calibration, and laboratory setups
• Intelligent building automation and energy management systems
• Integration into distributed EtherCAT architectures for scalable control solutions
• Robotics and motion control applications demanding fine-tuned analog outputs

Why Choose This Model?

• Unmatched Precision: Delivers 12-bit resolution for extremely accurate analog signal control, critical for sensitive applications.
• Space-Saving Design: Its compact 12 mm housing minimizes footprint in control cabinets, allowing for more efficient system layouts.
• Seamless Integration: Fully compatible with the EtherCAT I/O system and Beckhoff TwinCAT software, ensuring easy setup and reliable operation within existing Beckhoff ecosystems.
• Enhanced Reliability: Features robust electrical isolation and diagnostic LEDs, guaranteeing stable performance and simplifying troubleshooting.
• Versatile Application: Suitable for a broad range of industries, from manufacturing and process control to building automation and laboratory research.
• Proven Quality: Benefits from Beckhoff's decades of engineering expertise, offering a dependable and long-lasting solution for your automation needs.

Order Now

Elevate your industrial automation capabilities with the Beckhoff EL4024 4-channel analog output terminal. This robust and precise component is engineered to meet the demanding requirements of modern control systems, offering unparalleled performance and reliability. With its global availability, securing this essential terminal for your next project is straightforward. Enhance your control precision and streamline your operations by integrating the EL4024 today.
