Siemens 6ES7135-6HB00-0CA1

Overview

The Siemens 6ES7135-6HB00-0CA1 is a high-performance analog output module from the renowned SIMATIC ET 200SP series, engineered to deliver unparalleled precision and reliability for a wide array of industrial automation applications. This advanced module specializes in providing highly accurate voltage or current outputs, crucial for the precise control of processes and machinery. Designed with industrial demands in mind, it seamlessly integrates into existing SIMATIC ET 200SP systems, offering robust performance and simplified diagnostic capabilities. Its compact design belies its powerful functionality, making it an ideal choice for space-constrained industrial environments requiring dependable analog signal generation.

Key Features

• Dual Channel Precision: Equipped with 2 analog output channels for flexible control.
• High-Resolution Output: Delivers exceptional accuracy with 16-bit resolution.
• Versatile Output Types: Supports both voltage (±10V, ±5V, 0-10V, 1-5V) and current (±20mA, 0-20mA, 4-20mA) outputs.
• Superior Accuracy: Maintains signal integrity with a remarkable ±0.1% accuracy.
• Integrated Channel Diagnostics: Provides proactive monitoring for enhanced operational reliability.
• Broad BaseUnit Compatibility: Compatible with BaseUnit types A0 and A1 for flexible system integration.

Technical Specifications

• Model: Siemens 6ES7135-6HB00-0CA1
• Series: SIMATIC ET 200SP
• Product Type: Analog Output Module
• Output Channels: 2
• Output Ranges (Voltage): ±10 V, ±5 V, 0 to 10 V, 1 to 5 V
• Output Ranges (Current): ±20 mA, 0 to 20 mA, 4 to 20 mA
• Resolution: 16-bit
• Accuracy: ±0.1%
• Load Resistance (Voltage Output): ≥ 1 kΩ
• Load Resistance (Current Output): ≤ 500 Ω
• Settling Time: 0.05 ms (for resistive load)
• Diagnostics Functions: Short-circuit detection (voltage output), wire break detection (current output), monitoring of supply voltage
• Dimensions (W x H x D): 15 mm x 73 mm x 58 mm
• Weight: Approx. 38 g
• Operating Temperature: 0°C to +60°C
• Protection Class: IP20
• Compatible BaseUnits: Type A0, A1 (Color Code CC00)

Applications

• Process Control Systems: Ideal for precision control in chemical, pharmaceutical, and food & beverage industries.
• Automated Manufacturing: Essential for machinery and robotic systems requiring accurate analog signal manipulation.
• Building Management Systems: Enhances control and monitoring capabilities for HVAC and lighting systems.
• Energy Management: Facilitates precise regulation in power generation and distribution applications.
• Test and Measurement: Provides reliable analog outputs for laboratory and industrial testing environments.

Why Choose This Model?

• Unmatched Precision: Achieve superior control with 16-bit resolution and ±0.1% accuracy.
• Robust Industrial Design: Built by Siemens for durability and reliable operation in demanding environments.
• Flexible Connectivity: Supports a wide range of voltage and current output types to suit diverse applications.
• Enhanced Diagnostics: Integrated channel diagnostics ensure continuous monitoring and minimize downtime.
• Seamless Integration: Part of the SIMATIC ET 200SP family, ensuring easy setup and compatibility with existing systems.
• Compact Footprint: Its slim design saves valuable space in control cabinets.

Order Now

Elevate your industrial automation capabilities with the Siemens 6ES7135-6HB00-0CA1 SIMATIC ET 200SP Analog Output Module. Experience enhanced precision, reliability, and seamless integration for your critical applications. Don't compromise on performance—invest in Siemens quality today to optimize your operational efficiency and control. Secure your module now and take the next step towards advanced industrial automation.
