Mitsubishi RX41C4-TS

Overview

The Mitsubishi RX41C4-TS is a cutting-edge 4-channel analog output module meticulously engineered for seamless integration with the MELSEC iQ-R Series PLC systems. This versatile module delivers unparalleled precision with its high-resolution 16-bit digital-to-analog converters, enabling the generation of accurate voltage (0–10 V) or current (0–20 mA) signals. Beyond its primary function, the RX41C4-TS stands out with its integrated temperature sensor input, making it an indispensable component for sophisticated closed-loop control systems, advanced process automation tasks, and precision analog-driven instrumentation vital across a multitude of industrial applications. Its robust design and comprehensive features ensure reliable performance and enhanced control capabilities within demanding operational environments.

Key Features

• 4 Independent Analog Output Channels: Provides flexible control for multiple devices.
• 16-Bit High Resolution: Ensures superior accuracy and granular control over output signals.
• Selectable Voltage/Current Output: Adaptable for various industrial devices and systems (0-10V DC or 0-20mA).
• Integrated Temperature Sensor Support: Simplifies design for temperature-dependent control loops by accommodating RTD/thermocouple inputs.
• Channel-to-System Isolation: Enhances safety and prevents interference between outputs and the PLC system.
• Diagnostic LED Indicators: Offers quick visual status feedback for each output channel, aiding in troubleshooting.
• Compact R Series PLC Integration: Designed for easy and secure mounting within existing MELSEC iQ-R Series racks.

Technical Specifications

• Model: RX41C4-TS
• Series: MELSEC iQ-R Series
• Output Channels: 4 analog output channels
• Voltage Output Range: 0–10 V DC
• Current Output Range: 0–20 mA
• Resolution: 16-bit (equivalent to 0.15 mV or 3 µA per step)
• Load Resistance (Voltage): ≥ 2 kΩ
• Load Resistance (Current): ≤ 600 Ω
• Temperature Sensor Support: Configurable RTD/thermocouple type input
• Output Accuracy: ±0.1% of Full Scale (FS)
• Isolation Voltage: 1500 VAC
• Operating Temperature: 0 °C to 55 °C
• Storage Temperature: –25 °C to 75 °C
• Dimensions (Approx.): 90 mm (H) × 87 mm (W) × 40 mm (D)
• Weight (Approx.): 0.35 kg
• Certifications: CE, UL

Applications

• Precision process control systems (temperature, pressure, flow, level)
• Actuator and valve control via high-accuracy analog signals
• Advanced closed-loop control for manufacturing and industrial processes
• Integration with Human-Machine Interface (HMI) or SCADA systems for analog output commands
• Original Equipment Manufacturer (OEM) machine integration requiring reliable analog control
• Robotics and factory automation where adaptable analog signals are critical

Why Choose This Model?

• Unmatched Precision: Leverage 16-bit resolution for the most demanding control applications, ensuring fine-grained adjustments and stable operations.
• Exceptional Versatility: The ability to select between voltage and current outputs makes this module highly adaptable, reducing the need for multiple specialized units.
• Simplified System Design: With integrated temperature sensor support, complex wiring and additional components are minimized, streamlining installation and enhancing reliability.
• Robust Diagnostics: Per-channel LED indicators provide immediate feedback on operational status, significantly reducing downtime and simplifying maintenance tasks.
• Seamless Mitsubishi Integration: Designed specifically for the MELSEC iQ-R Series, it guarantees perfect compatibility and effortless integration into existing or new Mitsubishi PLC infrastructures.
• Global Accessibility: Available for worldwide shipping, ensuring that advanced automation capabilities are accessible wherever your operations are located.

Order Now
